摘要:目的 为太阳光热发电站不同于常规发电厂的系统，制定安全可靠、经济合理的消防设施设计标准，以保障电站的建设和安全运行。方法 利用现行的国家规范、标准，对太阳能光热电站采用的熔融盐、导热油的特性及其系统设备、建（构）筑物耐火等级进行分析判别；对电站采用的辅助燃料系统和消防给水的有关特殊消防设计问题进行分析探讨。结果 分析判别固态单体熔融盐火灾危险性为甲类、熔融态熔融盐火灾危险性为戊类，导热油火灾危险性为丙类，熔融盐、导热油系统建（构）筑物的火灾危险性为二级，根据火灾危险性等级提出具体的消防防火措施。结论 对电站采用熔融盐、导热油的火灾危险性类别分析判别结果符合现行的国家规范、标准，为太阳能光热电站工程的消防设计提供借鉴。Abstract:
Introduction For solar thermal power stations, which are different from conventional power plants, develop safe, reliable, economical and reasonable design standards for fire protection facilities to ensure the construction and safe operation of power stations. Method Utilize the current national codes and standards to analyze and judge the characteristics of molten salt and heat-conducting oil used in solar thermal power stations, their system equipment and the fire resistance rating of buildings (structures); Analysis and discussion on special fire protection design issues.Result Analysis and judgment: the fire hazard of solid monomer molten salt is Class A, the fire hazard of molten salt is E, the fire hazard of heat transfer oil is C, and the fire danger of molten salt and heat transfer oil system building is second-level, and specific fire prevention measures are proposed according to the fire danger level.Conclusion The analysis of the fire danger category of the power station using molten salt and heat-conducting oil is in accordance with the current national norms and standards, which provides a reference for the fire protection design of solar thermal power station projects.-
Keywords:
- solar power tower plant /
- molten salt /
- heat transfer oil /
- fire water supply
-
表 1 二元盐、三元盐特性表[1]
Table 1
Characteristic table of binary salt and ternary salt 内容 二元盐 三元盐 主要成分 40%KNO3，60%NaNO3 53%KNO3，7%NaNO3，40%NaNO2 工作温度/℃ 220～600 160～550 熔点/℃ 220 160 运动粘度/(mm2·s-1)(300℃) 0.81～0.84 0.79～0.82 液态比热容/(kJ·kg-1·K-1) 1.46 1.55 密度/(kg·cm-3) 1 899(300 ℃) 1 938(150 ℃) 导热系数/(W·m-1·K-1) 0.52 0.50
下载: 导出CSV
表 2 导热油特性表
Table 2
Characteristic table of heat transfer oil 导热油品牌 Dowtherm A VP-1 凝固点/℃ 12 12 沸点（常压）/℃ 257 257 闪点/℃ 113 124 着火点/℃ 118 127 自燃点/℃ 599 621 密度/(kg·cm-3) 1 056 1 060 准临界温度/℃ 497 499 准临界压力/ar 31.34 33.1 注： 表中的数据均来自导热油品牌网站，而非品牌厂家提供的正式资料。
下载: 导出CSV
-
[1] 汪琦，俞红啸，张慧芬. 熔盐和导热油蓄热储能技术在光热发电中的应用研究[J]. 工业炉, 2016, 38(3):34-38+48. WANGQ, YUH X, ZHANGH F. Application research of molten salt and heat conduction oil regenerative energy storage technology in solar-thermal power generation [J]. Industrial Furnace, 2016, 38(3):34-38+48.
[2] 何军. 熔盐和导热油蓄热储能技术在光热发电中的应用研究 [J]. 节能与环保, 2019(2):100-101. HEJ. Application of molten salt and heat conducting oil thermal storage technology in photothermal power generation [J]. Energy Conservation & Environmental Protection, 2019(2):100-101.
[3] 刘宏民，罗旭堃. 塔式光热电站设计标准建筑部分编制思路 [J].电力勘测设计, 2018(12):70-74. LIUH M, LUOX K. Writing thoughts for building provisions in code for design of solar tower thermal power plant [J]. Electric Power Survey & Design，2018(12):70-74.
